Grade 12 Ti-0.3Mo-0.8Ni Alloy Pipe Manufacturer
As a leading supplier of titanium and titanium alloy tubes in China, Daxun provides high-performance titanium tubes to the world.
- Titanium tube Grade：Grade 12 – UNS R53400
- Titanium tube types：Seamless Ti tube, Ti welded tube, forged Ti tube
- Titanium tube density The density of grade 12 titanium is approximately 4.51 g/cm3
- Standards：ASTM B338、ASTM B861
- Softest Ti,High ductility, Very corrosion resistant, good cold formability
————Daxun produces titanium tubes in China to meet the diverse and ——demanding needs of customers！
Grade 12 Titanium Alloy Pipe Manufacturer - Daxun Alloy
Provide High Quality Grade 12 Titanium Pipe to Customers Around The World
Grade 12 titanium pipe is a specialized tubing made from Ti-0.3Mo-0.8Ni titanium alloy, which belongs to a specific grade in the titanium alloy pipe family. This material is created by adding 0.3% molybdenum and 0.8% nickel to pure titanium, significantly enhancing its corrosion resistance, particularly in acidic environments and chloride media. Grade 12 titanium pipe complies with international standards such as ASTM B338 or ASTM B861, featuring a density of approximately 4.51 g/cm³, tensile strength of about 483 MPa, and yield strength of around 345 MPa, while maintaining the lightweight characteristics typical of titanium materials.
Where is Grade 12 titanium pipe used?
Compared to pure titanium, Grade 12 titanium pipe offers superior resistance to crevice corrosion and stress corrosion cracking, making it particularly suitable for chemical processing equipment, heat exchangers, oil and gas industries, and seawater treatment systems. This material provides longer service life and lower maintenance costs while maintaining excellent mechanical properties, making it highly favored in high-end industrial applications and an ideal choice for handling corrosive fluids.
Chemical processing plants utilize it for heat exchangers, reactor vessels, and piping systems handling aggressive acids and chlorides. Marine and offshore installations employ it in seawater cooling systems, desalination equipment, and subsea components, leveraging its exceptional resistance to saltwater corrosion and biofouling. In the oil and gas sector, it serves in downhole tubing, Christmas tree components, and production equipment exposed to sour environments with H₂S and CO₂. Power generation facilities specify Grade 12 titanium for condenser tubes and heat exchangers in cooling systems, while industrial pollution control systems incorporate it in scrubbers and flue gas desulfurization units that handle corrosive gases and acidic condensates.
Key Performance
Strength-Ductility Balance:
- Tensile Strength: 483 MPa (annealed state) – Matches Grade 2 but with superior corrosion resistance.
- Yield Strength: 345 MPa (min) – Exceeds Grade 2 (275 MPa), suitable for pressure-containing components.
- Elongation: 18% (min) – Exceptional ductility for cold forming, flaring, and high fatigue resistance.
- Density: 4.51 g/cm³ – 60% lighter than steel, ideal for weight-sensitive applications.
Corrosion Resistance:
- Core Mechanism: Synergistic effect of Molybdenum (0.3%) and Nickel (0.8%) stabilizes the passive oxide layer.
- Pitting/Crevice Corrosion Resistance:
- Outstanding performance in seawater, chloride solutions (e.g., NaCl, MgCl₂), and sour gas (H₂S) environments.
- Resists reducing acids (e.g., H₂SO₄, HCl) where stainless steels fail.
- Advantages vs. Other Grades:
- Outperforms Grade 2 in reducing acids and chlorides.
- Superior to Grade 9 in high-temperature acidic media (e.g., chemical processing).
- Immune to corrosion in oxidizing media (e.g., HNO₃) and aggressive chemical environments.
- Optimal Heat Treatment: Annealed at 595°C to maximize corrosion resistance and ductility.
Data
- Parameter
- Physical Properties
- Mechanical Properties
| Element | Minimum (%) | Maximum (%) |
|---|---|---|
| Titanium (Ti) | Balance | Balance |
| Molybdenum (Mo) | 0.25 | 0.40 |
| Nickel (Ni) | 0.60 | 0.90 |
| Iron (Fe) | — | 0.30 |
| Oxygen (O) | — | 0.25 |
| Carbon © | — | 0.08 |
| Nitrogen (N) | — | 0.03 |
| Hydrogen (H) | — | 0.015 |
| Other Elements | — | 0.40 (total) |
| Property | Value/Range | Unit |
|---|---|---|
| Density | 4.48 | g/cm³ |
| Melting Point | 1650 ± 20 | °C |
| Thermal Conductivity | 7.2 (at 25°C) | W/m·K |
| Specific Heat | 560 (at 25°C) | J/kg·K |
| Electrical Resistivity | 1.7 | μΩ·m |
| Magnetic Susceptibility | Paramagnetic | — |
| Property | Minimum Requirement | Typical Value | Unit | Test Method |
|---|---|---|---|---|
| Tensile Strength | 483 | 520–620 | MPa | ASTM E8/E8M |
| Yield Strength (0.2% offset) | 345 | 380–480 | MPa | ASTM E8/E8M |
| Elongation | 18 | 22–30 | % | ASTM E8/E8M |
| Hardness | ≤ 200 (HV) | 150–180 (HV) | Vickers | ASTM E10 |
| Impact Toughness | Not specified | 40–60 | J | ASTM E23 |
Elevated Temperature Performance
| Temperature (°C) | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
|---|---|---|---|
| 100 | 450–500 | 320–370 | 20–25 |
| 200 | 400–450 | 280–330 | 18–23 |
| 300 | 350–400 | 240–290 | 15–20 |
Choose Daxun to help your project take off.
Advanced Production:Titanium seamless pipe
- Titanium seamless tubes are hot rolled or hot extruded, straightened, processed with inner and outer diameters, and surface etched. Tubes can be supplied in heat-treated or non-heat-treated forms. Daxun has 100% ultrasonic testing capabilities. Hot rolled tube/hot extruded titanium seamless tube: outer diameter 1.0 mm to 325 mm, wall thickness 0.3 mm to 50 mm, length up to 12000 mm. Cold rolled titanium seamless tube: cold processed tubes are supplied after heat treatment, surface etching, hydrostatic test or ultrasonic inspection according to the requirements of the manufacturing specification. Outer diameter 6 mm to 102 mm, wall thickness 0.5 mm to 20 mm, length up to 9000 mm.
- (The above is agreed upon by the manufacturer and the customer based on the specific situation)
Grade 12 Titanium Tube Features
Grade 12 Titanium Tube is the softest form of titanium and has the highest ductility. It has good cold forming characteristics and offers excellent corrosion resistance. It also has excellent welding properties and high impact toughness.
- Softest Titanium
- Highest Ductility
- Excellent Corrosion Resistance
- Good Cold Formability
Advanced Production： Titanium Welded Tube
Titanium Welded Tube: Diameter ranges from 6.0mm to 1219mm, wall thickness ranges from 0.3mm to 30mm (depending on diameter), length up to 25000mm, made from Gr1 titanium tube. Welded tubes are made from flat rolled billets (tube blanks) on electric tube welding machines using automatic tungsten inert gas (argon) welding, and heat treated on the mill line. Mechanical tests, geometric measurements, 100% ultrasonic and eddy current testing, pneumatic or hydrostatic testing are performed before the finished titanium welded tubes are packaged according to customer specifications. Manufacturing technology as well as inspection and testing equipment ensure that thin wall welded tubes meet ASTM B 338 and ASME SB 338 specifications.
Test Reports
The test reports we provide include: Factory test certificate for Grade 12 titanium welded pipe and Grade 12 titanium seamless pipe, EN 10204 3.1, Chemical report, Mechanical report, PMI test report, Visual inspection report, Third-party inspection report, NABL approved laboratory report, Destructive test report, Non-destructive test report. (Daxun will provide according to customer’s requirements)
Applications and standards
Titanium Grade 12 Pipes and Tubing are extensively applied in extremely corrosive conditions in the below Industries：
- Chemical processing parts such as heat exchangers, reaction vessels, evaporators and delivery pipelines, automotive exhaust, oil and gas industry, petrochemical plants, chemical plants, industrial machinery, power industry, paper and pulp industry, food processing industry, refineries, pharmaceutical and food processing equipment, etc.
- Specifications : ASTM B861, B862, B338 / ASME SB861, SB862, SB338
Standard : ASTM, ASME and API
Quality, delivery, inspection
Daxun performs several quality assurance tests, these tests include flattening test, flaring test, ultrasonic flaw detection test, pitting and resistance test, mechanical test, hardness test, material positive identification, expansion test, etc. All these tests ensure that the Grade 12 Titanium Welded Pipe and Grade 12 Titanium Seamless Pipe materials are suitable for the required application. During the production process, we measure the diameter, thickness and surface of the products. Our standard delivery time is 5-7 days and the delivery time for special size products is 15-20 days.
- Our delivery time is strictly in accordance with the contract.
- Support customer third-party agencies to go to the factory for inspection
- Support free samples for customer testing
- Support on-site or video factory inspection
Packaging
Daxun Alloy ensures the best quality of packaging as it plays an important role in international freight where goods go through various channels to reach the final destination, so we pay special attention to packaging. We pack our goods in many ways depending on the product. We pack our products in many ways such as:
• Boxes and crates
• Shrink wrap
• Wooden pallets
• Wooden boxes
Technical Support
If you need any additional technical assistance, our resident metallurgist and knowledgeable staff will be pleased to help. Additionally, Daxun boasts a certified testing laboratory—a first in the multi-metal and plastic inventory industry. This, in our opinion, demonstrates our unwavering dedication to quality and our philosophy as a full-service supplier.
Daxun Grade 12 Titanium TUBE Let your brand improve rapidly
- Gallery
Grade 12 titanium tube form (4)
-
Titanium seamless tubes are made by piercing and drawing solid titanium bars, and the hollow part of the tube is made by piercing or hot extrusion. Titanium seamless tubes are ideal for very large diameter to wall thickness ratios and have very good external dimensional tolerances.
-
Titanium welded pipe is a tubular product made of strip titanium that is roll formed and fusion welded along the longitudinal seam. The welding process used by Daxun Alloy does not use any filler metal during the welding process.
-
Titanium square tubes are drawn from round tubes or round tube billets and can be formed into right angles or rounded corners. They can also be cold extruded, which is efficient and low cost. The only disadvantage is that the tolerance will gradually increase.
-
Tubular products are welded and then re-drawn to final size. Welding and drawing is ideal for producing thick walled, large diameter tubes that cannot be welded directly to size but still offer cost savings over seamless tubes. All Daxun welded and drawn tubes are bright annealed.
