Daxun has a full range of pure titanium plates and titanium alloy plates
- Grade:CP Grade 1 to Grade 18
- Type: Titanium and titanium alloy plates
- Hot rolled titanium plate 3.0mm-100mm
- Cold rolled titanium plate with thickness 0.3mm to 3.2mm
- Forged titanium plate: thickness 20mm-380mm
- Standards：ASTM ASME GB GJB DIN JIS
Applications and Usage for Titanium Sheet and Plate
In the past 20 years, our Titanium sheet and Plate have been widely used in aerospace, Chemical Processing, Marine Applications, Medical Devices, and Architecture. Daxun’s CP Grade 5 (also known as Ti-6Al-4V) can be used in Automotive and sports equipment. We are proud to see our product can take extreme temperatures (ATI 70 1,740°F, Melting Range 3,000 °F) and also use in the human body to provide a lightweight component to support individuals.
Daxun Alloy’s Titanium Sheet and Plate
Daxun is the leading Chinese manufacturer of titanium plates. We produce high-quality pure titanium plate. Check out our company profile to learn more about us. We are happy to provide all the technical documentation, testing certification, and quality assurance. Also, welcome to China to take a day tour of our factory. We believe in quality over quantity and have provided transparency and trust in business practice for the past 24 years.
Characteristics of various titanium plates
Each titanium plate material has its own different usage scenarios.
Industrial pure titanium plate, easy to weld, corrosion-resistant, and can work at 300°C for a long time.
Industrial pure titanium plate, easy to stretch and bend, can work at 300℃ for a long time.
High strength, light weight, good neutralizing performance, and can work at 400℃ for a long time
Suitable for aerospace parts production, high temperature resistance and high strength.
Forged titanium plates have good strength and toughness, and the grains are refined.
Titanium grade 5 belongs to α+β type titanium alloy and has good comprehensive properties.
Titanium and steel plate composite materials for power plant chimneys
Low density, corrosion resistance, acid and alkali resistance, light weight and easy to process.
Low density, corrosion resistance, acid and alkali resistance, light weight and easy to process.
Grade 12 titanium plates have better corrosion resistance than industrial pure titanium plates
Ti 6Al-4V sheet has been widely used in aerospace and military fields
Ti 6Al-4V plates and plates are α+β titanium alloys and have good overall properties.
Titanium plate production flow
With our reliable titanium plates, their properties can be customized to suit your application.
-
-
-
RolledAfter heating, it undergoes several rounds of rolling, then trimming and straightening to become a titanium plate.
-
-
Board trimmingRemove burrs and defects to improve the quality and finish of the board, making it flatter and smoother.
-
Inspection and deliveryTo ensure product quality, inspections ensure products meet quality standards.
Main features of titanium plate
The density of titanium metal is 4.506g/cm3
Titanium is 100 times more corrosion resistant than steel
Suitable for situations where magnetic field interference is avoided
Titanium alloy has high strength
Commercially Pure Titanium and Titanium Alloys
Pure Titainium:
CP Grade 1, CP Grade 2, CP Grade 3, CP Grade 4
Titanium Alloys:
CP Grade5 , Ti 6AL-4V
Other Available Titanium Product Grade:
Grade7, Grade 9, Grade 11, Grade 12, Grade 16, Grade 17, Grade 18
SPECIFICATIONS
- UNS R50250
- UNS R50400
- UNS R50550
- UNS R50700
- 3.7035
- ASME SB 265
- ASTM B265
- ASTM B348
- ASTM F67
- ISO 5832-2
PHYSICAL PROPERTIES For CP 1, 2, 3, 4:
Melting Range: 3,000-3,040°F, (1,649 – 1,671°C)
Density: 0.163 lbs/in³; 4.51 gm/cm³
Beta Transus Temperature:
DAXUN 30 1,630°F ± 25F° (888°C ± 4C°)
DAXUN 40 1,675°F ± 25F° (913°C ± 4C°)
DAXUN 55 1,690°F ± 25F° (921°C ± 4C°)
DAXUN 70 1,740°F ± 25F° (949°C ± 4C°)
Hardness
Typical annealed hardness in the annealed condition:
DAXUN CP Grade 2 Titanium is approximately Rockwell B80
CP Grade 4 titanium is approximately Rockwell B100
Corrosion Resistant Information
Our Tatanium’s low density and high strength provide good corrosion resistance.
| Nominal Composition | Forms | Coil | Sheet | Plate |
|---|---|---|---|---|
| CP Grade 1 | Ti | X | X | X |
| CP Grade 2 | Ti | X | X | X |
| CP Grade 3 | Ti | X | X | X |
| CP Grade 4 | Ti | X | X | X |
| CP Grade 7 | Ti (Gr2) 0.2 Pd | X | X | ** |
| CP Grade 11 | Ti (Gr1) 0.2 Pd | X | X | ** |
| CP Grade 16 | Ti (Gr2) 0.05 Pd | X | X | ** |
| CP Grade 17 | Ti (Gr1) 0.05 Pd | X | X | ** |
| * Produced to ASTM, AMS, ASME and MIL Specifications. ** Inquire with your sales representative. |
||||
SIZES,TOLERANCES
| Sheet | |
|---|---|
| Width** (in) | Thickness (in) |
| 24″ – 48″ | Up to 0.1874″ |
| Strip | |
| Width (in) | Thickness (in) |
| 0.250″ – 24″ | 0.001″ – 0.1874″ |
| Plate | |
| Width (in) | Thickness (in) |
| 96″ | 0.1875″ – 4.0″ x 360″ max |
* Sizes and tolerances vary. Inquire with your sales representative.
Product technical details and mechanical properties
For specific technical details, please view the individual product pages. We also could provide a design and fabrication handbook for industrial applications workbooks, Technical Data Sheets, certification, and price quotes. For non- commercially pure titanium, we will give exact alloying elements, metals, materials, and grades, oxygen, nitrogen for each product.
Who is Daxun Alloy?
At Daxun Alloy, we provide top-quality metal material. Our specialty is Pure titanium products like titanium plate, titanium alloys (CP grade 5 and other ti alloy product), and various stainless products. We offer a one-stop procurement, processing, logistics, and retail solution, which lowers costs and enhances our customers’ competitive advantage. We deliver excellent products and services efficiently. Our goal is to help customers achieve production goals quickly. We are pro metal manufacturers and can offer a wide range of metal products.
Meet us on a tour trip in China?
No problem, we will arrange for you to take you to our factory directly. If you can’t come, a video call is also a good way to see how we are manufacturing your orders. Our strength is trust and transparency.
Related Products:
Daxun Alloy
Regarding titanium plates, we can handle any type of inquiry. Please feel free to ask us. We will make recommendations based on each client’s needs.
Yes, we have complete specifications and inventory and can quickly meet your needs.
Yes, it can be customized. You can contact us and send us the customized specifications and quantity.
Our transportation methods generally include sea transportation, land transportation, and sea transportation. Reach you quickly and safely.
Because our output is high, the cost will be much lower, so the price is low.
We attach great importance to product quality and have passed various quality system tests.
